Auto Hematology Analyzer (VX-h360)

Auto Hematology Analyzer (VX-h360)

The VX-h360 is a compact 3-part hematology analyzer designed for efficient clinical use. It processes up to 60 samples per hour in both whole blood and pre-diluted modes, ensuring flexible operation. Equipped with a 10.4-inch color touchscreen and dual counting channels, it provides 21 hematological parameters complete with histograms and alert functions. Additional features include a built-in thermal printer, USB connectivity, and ample data storage capacity for seamless workflow.

Download Catelog (PDF)

Description

Technical Specifications
Principle Impedance method (WBC, RBC, PLT) and cyanide-free colorimetric method (HGB)
Sample Type Whole blood, pre-diluted blood
Screen Size 10.4 inch color display screen with touch panel
Data Transmission USB, Bi-directional LIS
Power Supply 100–240VAC, 50/60Hz, 150VA
Operating System Embedded system
Weight 24.30 KG
Dimension 420 (L) × 295 (W) × 430 mm (H)
Testing Speed 21 tests/hour
Data Storage Volume 500,000 records
Language Interface Multi-language
Printer Built-in thermal printer, supports HP printers
Reagent Card Code 3-part diluent and lyse
