Description
| System Function |
| Throughput |
Constant 200 tests/hour, up to 330 tests/hour with ISE |
| Measuring Principles |
Absorbance photometry, Turbidimetry, Ion Selective Electrode (ISE) technology |
| Methodology |
End-point, Fixed-time, Kinetic, optional ISE single/dual reagent chemistries, monochromatic / bi-chromatic |
| System Type |
Open system with user-defined profiles and calculations |
| Reagent / Sample Handling |
| Reagent / Sample Tray |
40 positions for reagents and 40 positions for samples in a 24-hour refrigerated compartment (2~12°C) |
| Reagent Volume |
R1: 10~350µl (1µl step); R2: 10~200µl (1µl step) |
| Sample Volume |
2~45µl (0.1µl step), supports primary tubes and different sample cups |
| Reagent / Sample Probe |
Liquid level detection, vertical & horizontal collision protection, inventory checking, reagent pre-warming |
| Probe Cleaning |
Automatic washing for interior and exterior, carry-over < 0.1% |
| Automatic Sample Dilution |
Supports pre-dilution and post-dilution |
| Control and Calibration |
| Calibration Mode |
Linear (one-point, two-point, multi-point), Logit-Log 4P, Logit-Log 5P, spline, exponential, polynomial, parabola |
| Control Rules |
X-R, L-J, Westgard multi-rule, cumulative sum check, twin plot |
| Working Conditions |
| Power Supply |
200~240V, 50/60Hz, ≤1500W or 100~130V, 50/60Hz, ≤1500W |
| Operating Temperature |
15~30°C |
| Humidity |
35~85% RH |
| Dimensions |
860mm (W) × 700mm (D) × 625mm (H) |
| Weight |
130 kg |
| Cuvette Washing |
8-stage washing station with pre-warmed detergent and water |
